When you
have heavy read workloads, where a relatively small amount of data is scanned by
multiple queries, you can offload queries (reads) either from an elastic pool leader
or from an elastic pool member to Refreshable Clones.
About Query Offloading Provides information about using query offload with an elastic pool and describes the query offload features.
Enable Query Offload Describes how to enable query offload for an elastic pool leader or for an elastic pool member.
Disable Query Offload Describes how to disable query offload for an elastic pool leader or for an elastic pool member.
Query Offload from PL/SQL When query offload is enabled, queries are offloaded to Refreshable Clones even if they are embedded within PL/SQL. The PL/SQL can be stored procedures, functions, packages, or anonymous blocks.
Query Offload from a Scheduler Job When query offload is enabled, queries from within an Oracle Scheduler job action are offloaded to Refreshable Clones. The queries are offloaded whether the job runs in the foreground or in the background.
Provides
information about using query offload with an elastic pool and describes the query
offload features.
Elastic pool query offload provides performance benefits by allowing
one or more Refreshable Clones to handle queries for either an elastic pool
leader or for an elastic pool member. This feature also allows you to add
Refreshable Clones to accommodate increasing query (read) demand. Offloading
queries allows your application to scale horizontally, where you can add
Refreshable Clones to maintain overall system performance as needed to
satisfy your query request volume.
When query offload is enabled, queries are submitted either to the
elastic pool leader or to an elastic pool member and one or more available
Refreshable Clones become candidates for query offloading. In addition, when
more Refreshable Clones are added, query offload dynamically adjusts to make
use of the new resources.
One use case for query offload is to enable the feature during peak
hours to take load off of either the elastic pool leader or an elastic pool
member. During quiet hours, you can disable query offload to perform
maintenance operations such as refreshing the Refreshable Clones.
By default query offload considers queries from any session.
Alternatively you can offload queries from a list of sessions that you
specify by module or action name.
The following figure shows offloading queries from the elastic pool leader.
Data on the Refreshable Clones is up to date based on the last
refresh time for each refreshable clone. This means when query offload is
enabled you perform all DDL, DML and PL/SQL operations either on the elastic
pool leader or on the elastic pool member that is offloading queries. Then,
after a Refreshable Clone is refreshed, the changes are reflected on the
Refreshable Clone.
Dynamic Addition: Refreshable Clones may be added
as members of the elastic pool at any time. Query
offload dynamically adjusts to make use of new
members.
Dynamic Removal: Refreshable Clones may be removed
as members of the elastic pool at any time. Query
offload dynamically adjusts to stop offloading
queries to a Refreshable Clone that has been removed
from the elastic pool.
Session Based Sticky Offload: Query offload is
sticky within a session, meaning if a query in a
session has been offloaded to a particular
Refreshable Clone, then query offload uses the same
Refreshable Clone to offload subsequent queries in
the same session.
One-to-One Service Mapping: There is
a one-to-one mapping between the service used in
either in the elastic pool leader or the elastic
pool member by the original query and the service
used in a Refreshable Clone for any offloaded query.
For example, if a session is connected to the MEDIUM
service, then query offload for that session also
uses the MEDIUM service on the Refreshable
Clone.
Determine if Session is Offloaded:
Using a SYS_CONTEXT query you can
determine if a session runs on the elastic pool
leader or member, or is offloaded to a Refreshable
Clone.
Query Offload from PL/SQL: Queries are offloaded
to a Refreshable Clone even if they are embedded
within PL/SQL. The PL/SQL can be stored procedures,
functions, packages, or anonymous blocks.
Query Offload from Scheduler Job: Queries from
within an Oracle Scheduler job actions are
offloaded. Oracle Scheduler job queries are
offloaded whether the job runs in the foreground or
in the background.
DBA_PROXY_SQL Views
Use the DBA_PROXY_SQL views
DBA_PROXY_SQL_ACTIONS and
DBA_PROXY_SQL_MODULES to display the list of
modules or actions that are configured for query offload. You must
query these views from a session that is not enabled for query
offload.
Describes
how to enable query offload for an elastic pool leader or for an elastic pool
member.
The following are requirements for enabling query
offload:
You can enable query offload for an elastic
pool leader or for an elastic pool member with no
Refreshable Clones. After you enable query
offloading you can add Refreshable Clones and the
query offload feature dynamically adjusts to make
use of the refreshable clones.
A Refreshable Clone that is a candidate for
query offload must:
Have the elastic pool leader as
its source database and be in the same region as
the elastic pool leader.
or
Have an elastic pool member as its
source database and be in the same region as the
elastic pool member.
Be an elastic pool member.
To enable query offload:
Verify that the Autonomous Database instance is an elastic pool leader or
an elastic pool member:
Use the following query to verify that an
instance is an elastic pool leader:
SELECT sys_context('userenv', 'is_elastic_pool_leader') FROM DUAL;
This query should return
YES.
Use the following query to verify that an
instance is an elastic pool member:
SELECT sys_context('userenv', 'is_elastic_pool_member') FROM DUAL;
This query should return
YES.
Note
There
may be a delay of up to 15 minutes for the
sys_context value to reflect the
current value if the elastic pool has recently been
created or modified.
Enable query offload.
There are two choices: you can enable query
offload for queries from any session or limit query
offload to the sessions you specify by module or
action name.
To enable query offload for all
sessions run DBMS_PROXY_SQL.ENABLE_READ_ONLY_OFFLOAD
without parameters. For example:
EXEC DBMS_PROXY_SQL.ENABLE_READ_ONLY_OFFLOAD;
To enable query offload for specific
sessions by module name or action name, run DBMS_PROXY_SQL.ENABLE_READ_ONLY_OFFLOAD
with the module_name or
action_name parameters.
When query offload is enabled for a session you can find the
name of the Refreshable Clone to which queries are offloaded. For
example, from the session run this query:
SELECT sys_context('userenv', 'con_name') FROM DUAL;
If queries are not being offloaded to a Refreshable Clone
this query shows the name of the elastic pool leader (or of the
elastic pool member that is not a refreshable clone).
Enable Query Offload for Named Modules or
Actions 🔗
Describes
how to enable query offload for sessions with named modules or actions.
To enable query offload for specific sessions by module name or action
name:
Verify that the instance is an elastic pool leader or an
elastic pool member.
Use the following query to verify that an
instance is an elastic pool leader:
SELECT sys_context('userenv', 'is_elastic_pool_leader') FROM DUAL;
This query should return
YES.
Use the following query to verify that an
instance is an elastic pool member:
SELECT sys_context('userenv', 'is_elastic_pool_member') FROM DUAL;
This query should return
YES.
Note
There
may be a delay of up to 15 minutes for the
sys_context value to reflect the
current value if the elastic pool has recently been
created or modified.
Use the routines SET_ACTION or
SET_MODULE in
DBMS_APPLICATION_INFO to set the
module name and or the action name in the current
session.
For example
CREATE or replace PROCEDURE add_employee(
name VARCHAR2,
salary NUMBER,
manager NUMBER,
title VARCHAR2,
commission NUMBER,
department NUMBER) AS
BEGIN
DBMS_APPLICATION_INFO.SET_MODULE(
module_name => 'add_employee',
action_name => 'insert into emp');
INSERT INTO emp
(ename, empno, sal, mgr, job, hiredate, comm, deptno)
VALUES (name, emp_seq.nextval, salary, manager, title, SYSDATE,
commission, department);
DBMS_APPLICATION_INFO.SET_MODULE(null,null);
END;
When query offload is enabled for a session, from the
session you can find the name of the Refreshable Clone to which
queries are offloaded. For example:
SELECT sys_context('userenv', 'con_name') FROM DUAL;
If queries are not being offloaded to a Refreshable Clone
this query shows the name of the elastic pool leader (or of the
elastic pool member that is not a refreshable clone).
The views DBA_PROXY_SQL_ACTIONS and
DBA_PROXY_SQL_MODULES display the list of
modules or actions that are configured for query offload. You must
query these views from a session that is not enabled for query
offload. See DBA_PROXY_SQL Views for more information.
When query offload is enabled, queries are offloaded to
Refreshable Clones even if they are embedded within PL/SQL. The PL/SQL can be stored
procedures, functions, packages, or anonymous blocks.
For example, you can demonstrate a query being offloaded to a
Refreshable Clone when you enable query offload for a specific module and
action. In this example, assume that the leader's data has been updated and
the Refreshable Clone has not yet been updated (so the Refreshable Clone's
data is out of date and different). In this example, with different values
on the elastic pool leader and the Refreshable Clone, you can see when data
is coming from either the leader or from the Refreshable Clone.
Enable query offload and specify the eligible
sessions by module name and action name. For example,
'mod1',
'act1'.
SQL> create or replace function f1 (n number)
2 return number
3 as
4 l_cnt number;
5 begin
6 select sum(c1) into l_cnt from u2.tab1;
7 return l_cnt;
8 end;
9 /
Function created.
Run the function f1. The query with
function f1 runs on the elastic pool leader
(or on an elastic pool member that has offload query
enabled). This session runs with unspecified module and
action names that do not match those specified for query
offload in Step 1.
SQL> -- expected to fetch from Elastic Pool Leader and returns value 40
SQL> select f1(3) from dual;
F1(3)
----------
40
1 row selected.
Specify the module name and action name for the
session to match the names specified in Step 1. The queries
from this session are now eligible to be offloaded to a
Refreshable Clone.
Run the function f1 again. In this
case the module name and action name match the names
specified in Step 1. The query in function
f1 is offloaded to a Refreshable
Clone.
SQL> -- Expected to fetch from Refreshable Clone and returns value 10
SQL> select f1(3) from dual;
F1(3)
----------
10
1 row selected.
Specify the module and action names as something
other than mod1 and act1.
The queries from this session are no longer eligible to be
offloaded to a Refreshable Clone, due to the module and
action names not matching those specified in Step 1.
Run the query with function f1.
Because the module and action name for this session do not
match those set in Step 1, this query is not offloaded and
runs on the elastic pool leader.
SQL> -- expected to fetch from Elastic Pool Leader and returns value 40
SQL> select f1(3) from dual;
F1(3)
----------
40
1 row selected.
When query offload is enabled, queries from within an Oracle
Scheduler job action are offloaded to Refreshable Clones. The queries are offloaded
whether the job runs in the foreground or in the background.
For example, similar to the previous example for PL/SQL, you can
demonstrate a query being offloaded to a Refreshable Clone when you enable
query offload for an Oracle Scheduler job. In this example, assume that the
leader's data has been updated and the Refreshable Clone has not yet been
updated (so the Refreshable Clone's data is out of date and different). In
this example, with different values on the elastic pool leader and the
Refreshable Clone, you can see when data is coming from either the leader or
from the Refreshable Clone.
SQL> create or replace procedure sproc1 (n number)
2 as
3 l_cnt number;
4 begin
5 select sum(c1) into l_cnt from u2.tab1;
6 dbms_output.put_line('l_cnt is ' || l_cnt);
7 end;
8 /
Procedure created.
Offload Queries from Elastic Pool Leader to Member Refreshable Clones
SQL> create or replace procedure sproc1 (n number)
2 as
3 l_cnt number;
4 begin
5 select sum(c1) into l_cnt from u2.tab1;
6 dbms_output.put_line('l_cnt is ' || l_cnt);
7 end;
8 /
Procedure created.
SQL>
SQL> BEGIN
2 dbms_scheduler.create_job(job_name => 'PROXYTEST1',
3 job_type => 'PLSQL_BLOCK',
4 job_action => 'BEGIN sproc1(3); END;',
5 enabled => FALSE);
6 END;
7 /
PL/SQL procedure successfully completed.
SQL>
SQL> -- Job runs in the foreground in the current session
SQL> -- expected to fetch from Leader: 40
SQL> exec dbms_scheduler.RUN_JOB(job_name => 'PROXYTEST1', use_current_session => true);
l_cnt is 40
PL/SQL procedure successfully completed.
SQL>
SQL> exec dbms_proxy_sql.enable_read_only_offload;
PL/SQL procedure successfully completed.
SQL> show con_name
CON_NAME
------------------------------
CDB1_PDB1
SQL>
SQL> set serveroutput on
SQL> -- Job runs in the foreground in the current session
SQL> -- expected to fetch from Refreshable Clone: 10
SQL> exec dbms_scheduler.RUN_JOB(job_name => 'PROXYTEST1', use_current_session => true);
l_cnt is 10
PL/SQL procedure successfully completed.
SQL>
SQL> -- Job runs in the background and is expected to fetch from Refreshable Clone: 10
SQL> exec dbms_scheduler.RUN_JOB(job_name => 'PROXYTEST1', use_current_session => false);
PL/SQL procedure successfully completed.
Provides additional notes for the query offload
feature.
Notes for query offload:
Addition or Removal of a Refreshable Clone: When a
Refreshable Clone is added as an elastic pool member, there
can be a delay of up to fifteen minutes for the addition to
be reflected in the elastic pool leader. A newly added
Refreshable Clone is not considered as a target for query
offloads until the leader is aware of the newly added
elastic pool member.
Similarly, when a Refreshable Clone is removed from the elastic
pool, there can be a delay of up fifteen minutes for the
removal to be reflected in the elastic pool leader. The
removed Refreshable Clone is considered as a target for
query offloads until the leader knows that the member has
been removed from the elastic pool.
Refresh of Refreshable Clone: When a Refreshable Clone is
being refreshed, queries that are offloaded to the
Refreshable Clone may be delayed.
Public and Private Endpoint Support: Query
offload is supported for instances on a public endpoint and
for instances on a private endpoint.
Disconnected Refreshable Clone: If a
Refreshable Clone becomes disconnected, it is no longer
eligible as a target for query offload. There can be a delay
of up to fifteen minutes for the elastic pool leader to
detect that a Refreshable Clone has become disconnected and
to stop offloading queries to it.
To ensure that a Refreshable Clone remains available for query
offloading, either enable automatic refreshes or
periodically manually refresh the Refreshable Clone.
Case Sensitive Module Name and Action Name:
When you offload queries from a list of sessions that you
specify by module or action name, the module name and action
name set with DBMS_APPLICATION_INFO are
case sensitive. DBMS_PROXY_SQL.ENABLE_READ_ONLY_OFFLOAD
adheres to this case sensitive behavior. For example, when a
session has a lowercase module name, or mixed case module
name, the case must match in the parameter values when you
enable query offload with DBMS_PROXY_SQL.ENABLE_READ_ONLY_OFFLOAD
and you include the module_name or
action_name parameters.
You can check the module name and action name for the current
session using
DBMS_APPLICATION_INFO.READ_MODULE:
Typical Use Case: One use case for query
offload is to enable the feature during peak hours to take
load off of the Elastic Pool Leader (or off of the Elastic
Pool Member where query offload is enabled). During quiet
hours, you can disable query offload to perform maintenance
operations such as refreshing the Refreshable Clones.
